Specifications
|
|
Visual recognition system
|
Discrimination method
|
Color image contrast
|
|
video camera
|
CCD color camera, resolution: 12 μ M / point,
|
|
light source
|
RGB ring LED structure light source
|
|
Image processing speed
|
0402 Chip
|
< 9ms
|
|
Processing time of each picture
|
< 150ms
|
|
Test content
|
Solder paste printing
|
Missing print, skew, connecting tin, less tin, more tin, open circuit, pollution
|
|
Part defect
|
Missing parts, deviation, skew, stele, side standing, turnover, reverse polarity, wrong parts, damage
|
|
Solder joint defect
|
More tin, less tin, even tin, faulty soldering
|
|
Anti static measures
|
Anti static socket, anti-static ring
|
|
mechanical system
|
PCB size
|
minimum：25mm×25mm， maximum：380mm×480mm
（Larger specifications can be customized according to the specific requirements of customers）
|
|
PCB thickness
|
0.5mm~2.5mm
|
|
PCB Warpage
|
<2mm（Deformation correction assisted by fixture）
|
|
Part height
|
<30mm
|
|
Minimum part
|
0201Chip
|
|
X、Y platform
|
Drive equipment
|
AC servo motor system
|
|
Accurate positioning
|
<25 um (0.025mm)
|
|
Movement speed
|
700mm/s
|
|
software system
|
operating system
|
support Windows XP、Windows 2000、Windows 2003
|
|
Pre assembly Windows XP
|
|
Identification control system
|
characteristic
|
Statistical shape modeling, learning OK samples, automatic establishment of standard image, recognition data and error threshold
|
|
operation
|
Graphic programming, built-in component library, automatic generation of detection frame according to component shape selection standard, accurate automatic positioning, micro position fine adjustment, fast manufacturing process
|
|
Mark
|
point
|
0 ~ 2 common mark points can be selected
|
|
Recognition speed
|
0.5s/pcs
|
|
Control system
|
IPC
|
E5500 3.0G，DDR 2G，HDD 250G
|
|
display
|
19 inch LED Widescreen display
|
|
Other parameters
|
Mechanical Dimensions (L*W*H)
|
860mm * 960mm * 1560mm
|
|
weight
|
450Kg
|
|
Power Supply
|
AC220V/-10%，50/60Hz，600W
|
|
remarks
|
The above is standard configuration, all parameters can be customized according to customers.
|
